Multiswitch MS 4-in-4-out S

Multiswitch MS 4-in-4-out S SHEET METAL HOUSING 5×4,13/18V &22kHz Multiswitches: Model MS44S,Model MS54S FEATURES 1.MS44S:4 SAT & 1 Terr.TV inputs to 4outputs for satellite receivers. MS54S:4 SAT inputs to 4outputs for satellite receiver. 2.Built-in amplification circuit to compensate cable loss. 3.Sheet metal housing with plastic. SPECIFICATION 1.Frequency Range:SAT 950-2150MHz 2.Insertion Loss:SAT 6dB 3.Switching Isolation:25dB 4.Isolation30dB 5.Rejection:22dB 6.Return Loss:10dB 7.SAT Output Level(dB):100@35dBIMA3,EN50083-3 8.Built-in Power Supply:W/O 9.Dimension:190×120×43mm
